前言:
笔者在开发过程中一直困扰与页面样式及其用户体验等问题。为了解决这些问题从而提高系统开发效率和增强人机交互能力,所以在网上一直寻找解决方案。
最终决定使用Ext.net进行开发。
Ext.Net介绍:
是一组开源的Asp.net(WebForm,MVC)组件。基于Ext.Js库开发,含有100多个工具,如TextBox,Combox,Button,ToolBar,StateBar,Panel,TabPanel,ExplorerBar,MenuBar,PictureBox 等多种控件并支持Ajax无刷新效果。
下载地址:
示例地址:
环境:VS2005+、服务器.NET Framework3.5+、网站系统.net 2.0+
Ext.Net特点:
1.多种控件。能快速的创建高视觉的用户界面
2.300多个示例,能让你快速上手
3.丰富的Ext.js API提供支持
4开源闭源双协议
Ext.Net安装和使用
1.下载最新版本
2.打开下载文件,将包含以下文件:
Ext.Net.dllExt.Net.Utilities.dllExt.Net.xmlNewtonsoft.Json.dllNewtonsoft.Json.xml
3.打开 Visual Studio,创建C#网站项目
- 打开菜单创建网站
- 弹出"创建网站"窗口,选择Asp.net 网站,位置:文件系统, 语言:Visual C#
- 点击确定
4.首次使用时
- 在工具箱中右键点击"添加选项卡"
- 选项卡名称Ext
- 在该选项卡中,右键点击“选择项”
- 弹出"选择箱项"对话框,点击“浏览” ,双击选择下载文件目录下的"Ext.Net.dll"
- 点击“确定”,将在Ext选项卡中出现多个控件
5.配置Web.Config
<? xml version="1.0" encoding="utf-8" ?> < configuration > < configSections > < section name ="extnet" type ="Ext.Net.GlobalConfig" requirePermission ="false" /> < configSections > < extnet /> <!-- The following system.web section is only requited for running ASP.NET AJAX under Internet Information Services 6.0 (or earlier). This section is not necessary for IIS 7.0 or later. --> < system.web > < httpHandlers > < add path ="*/ext.axd" verb ="*" type ="Ext.Net.ResourceHandler" validate ="false" /> </ httpHandlers > < httpModules > < add name ="DirectRequestModule" type ="Ext.Net.DirectRequestModule, Ext.Net" /> </ httpModules > </ system.web > <!-- The system.webServer section is required for running ASP.NET AJAX under Internet Information Services 7.0. It is not necessary for previous version of IIS. --> < system.webServer > < validation validateIntegratedModeConfiguration ="false" /> < modules > < add name ="DirectRequestModule" preCondition ="managedHandler" type ="Ext.Net.DirectRequestModule, Ext.Net" /> </ modules > < handlers > < add name ="DirectRequestHandler" verb ="*" path ="*/ext.axd" preCondition ="integratedMode" type ="Ext.Net.ResourceHandler" /> </ handlers > </ system.webServer > </ configuration >
6.打开default.aspx。顶部添加:
<% @ Register Assembly = " Ext.Net " Namespace = " Ext.Net " TagPrefix = " ext " %>
7.页面<form>中添加:
<!-- 必须的 --> < ext:ResourceManager ID = " ResourceManager1 " runat = " server " />
8.拖入一个Ext控件到页面。
如:
< ext:CycleButton ID = " CycleButton1 " runat = " server " ShowText = " true " PrependText = " View As " > < Menu > < ext:Menu ID = " Menu1 " runat = " server " > < Items > < ext:CheckMenuItem ID = " CheckMenuItem1 " runat = " server " Text = " Text Only " Icon = " Note " /> < ext:CheckMenuItem ID = " CheckMenuItem2 " runat = " server " Text = " Html " Icon = " Html " Checked = " true " /> </ Items > </ ext:Menu > </ Menu > </ ext:CycleButton >
9.页面点击右键“在浏览器中查看”
从此你爱上了Ext.net。。。
